battery-powered rail coachscrewing machine

Battery-powered rail coachscrewing machine is a new product developed by our company in accordance with international requirements for environmental protection. Using lithium battery as energy source, low-voltage and high-current DC motor as power, it has the characteristics of small size and high power. It is suitable for the tightening operation of ordinary sleeper vertical bolts, turnout sleeper vertical bolts, and high-speed railway sleeper plate vertical bolts.

BENEFITS

*36V super endurance trolley impact Li-battery Wrench

*Super endurance capability, 3000 bolts are loosened and tightened per charge (M27 Bolt）

*Intelligent torque adjustable design, the operator can set the working torque according to the actual working conditions

*Intelligent electronic control technology, the actual working torque will not change with the decrease of battery power

*Intelligent digital display, working torque and real-time power digital display

*The whole machine is waterproof and can work in rainy days, and can also work under minus 30 degrees

*The whole machine is 41 kg, which can be quickly disassembled and assembled, which is convenient for loading and unloading without additional tools

SPECIFICATION

Rated power
2Kw (brushless DC motor)
No-load speed
0-1200rpm
Frequency
0-2300 bpm
Maximum tightening torque
3000Nm
Maximum unscrewing torque
3500Nm
Switch type
Three switches, safety start switch and forward and reverse switch
Illumination
Dual LED lights
Adjustable torque range
digital display 80-500Nm (10Nm increment adjustment)
Tightening time of M24 bolts
3~5s
Weight
≤41.5Kg (including sleeve and battery pack)
Operating temperature requirements
minus 30°C~45°C
Rated voltage of battery
36V
Rated capacity of battery
36Ah
Endurance
3000 bolts are loosened and tightened per charge (M27 Bolt）
Battery life
1000 cycle times of charge
Waterproof rating of the whole machine
IP45 (safe to use even in heavy rain)
